22.2 Connection Cable
22.2.1 RS-232 cable
22 - 11
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
2 Connector specifications
(1) GOT side connector
Use the following as the RS-232 interface and RS-232 communication unit connector on the GOT.
For the GOT side of the RS-232 cable, use a connector or connector cover applicable to the GOT
connector.
(a) Connector type
9-pin D-sub (male) inch screw fixed type
(b) Connector model
*1 For the confirmation method of GT15 hardware version, refer to the following manual.
GT15 User's Manual
(2) RKC temperature controller side connector
Use the connector compatible with the RKC temperature controller side module.
For details, refer to the following manual.
User's Manual for the RKC temperature controller
3 Precautions when preparing a cable
The length of the RS-232 cable must be 15m or less.
GOT
Hardware
version*1
Model Manufacturer
GT1595-X A 17LE-23090-27(D3CC) DDK Ltd.
GT1585-S
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B 17LE-23090-27(D3CC) DDK Ltd.
GT1575-S
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B 17LE-23090-27(D3CC) DDK Ltd.
GT1575-V
A GM-C9RMDU11 Honda Tsushin Kogyo Co., Ltd.
B
17LE-23090-27(D3CC) DDK Ltd.
GT1575-VN
A
GT1572-VN
GT1565-V
GT1562-VN
GT11
GT15-RS2-9P

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
