22.4 Temperature Controller Side Setting
22.4.1 Connecting to H-PCP-J
22 - 33
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
(1) Transmission speed settings
(a) COM.PORT1/COM.PORT2
(b) COM.PORT3
(2) Communication mode settings
(a) COM.PORT1/COM.PORT2
(b) COM.PORT3
SW2
Communication speed
3 4
OFF OFF 9600bps
ON OFF 19200bps
OFF ON 38400bps
SW3
Communication speed
3 4
OFF OFF 9600bps
ON OFF 19200bps
OFF ON 38400bps
SW2
Communication protocol
5 6 7 8
ON OFF OFF OFF MODBUS protocol
SW3
Communication protocol
5
ON MODBUS protocol
