4 - 14
4.6 Drawing Check
4.6 Drawing Check
4.6.1 Drawing check function
The drawing check function carries out display checks as missing bit check, color check, basic figure display check, move
check among screens.
4.6.2 Display operation of drawing check
POINTPOINTPOINT
Notes on drawing check
Missing bits is occurred in the following cases.
When missing bits occurs, contact your local Mitsubishi (Electric System) Service.
1. There are parts drawn in different color with the filled color.
2.
There are parts of basic figure and drawing patterns which are not drawn according to the layout and
procedures described in "4.6.2
Display operation of drawing check".
Drawing check
Maintenance
Touch
[Drawing check].
