11.1 Standard I/F

11 - 3

COMMUNICATION INTERFACE SETTING (COMMUNICATION SETTING)

11.1.3 Display contents of standard I/F

Described below are the display items on the standard I/F menu and their functions.

■1. Display item

Driver display BOX
