Mitsubishi GOT2000 Series - Position Correction of the Touch Panel (Touch Panel Calibration Setting)

12.2 Operation Settings (Settings for Operation)
12 - 9
DISPLAY AND OPERATION SETTINGS (GOT SET UP)
12
12.2.4 Position correction of the touch panel (touch panel calibration setting)
■1. Touch panel calibration setting function
Touch panel reading error can be corrected.
Normally the adjustment is not required, however, the difference between a touched position and the object position
may occur as the period of use elapses.
When any difference between a touched position and the object position occurs, correct the position with this function.
■2. Touch panel calibration setting display operation
Run Stop Run Stop
The [Run] will operate though you
intended to touch the [Stop] button.
The [Stop] button can be touched
without fail.
After adjustmentBefore adjustment
Touch
[Calibration].
Main menu
GOT setup
Operation
Operation
Touch panel calibration
Touch
[Operation].
Touch
[GOT Setup].
