8 - 2
8.2 Error Codes and System Alarm List
8.2 Error Codes and System Alarm List
■1. Error codes displayed on the GOT
The following shows the error codes displayed on the GOT and the relevant manuals.
(1) GOT error codes and network error codes
*1 For the details of the GOT special registers (GS262 to GS264), refer to the following.
➠ GT Designer3 (GOT2000) Help
*2 For a system alarm related to the file access, the drive where the alarm has occurred cannot be identified.
To identify the drive where the alarm has occurred, check the File Access Error signals (System signal 2-2.b7 to b10).
*3 Channel No. will not be stored depending on the error code.
For the details of the channel No. storage by error code, refer to the following.
➠ ■3. System alarm list
(2) Controller error codes
*1 For the details of the GOT special registers (GS262 to GS264), refer to the following.
➠ GT Designer3 (GOT2000) Help
*2 For the FXCPU, error code 100 to 109 correspond to M8060 to M8069 respectively.
Example) For error code 100, take the corrective action for M8060.
*3 For the hexadecimal error code of the servo amplifier, the GOT displays the error code in decimal incremented by 2000.
When referring to the manual of servo amplifier by the error code displayed as a GOT system alarm, subtract 20000 from the
GOT error code and change its lower three digits to the hexadecimal number.
Example) The GOT system alarm 20144 refers to the servo amplifier error code 90H.
■2. Identification/manufacturer/classification code of the system alarm
A system alarm contains an identification code, manufacturer code, and classification code. The identification code
indicates the category of the error. The manufacturer code and classification code indicate the area where the error
occurred.
The following shows the details of the identification code, manufacturer code, and classification code.
(1) Identification code
(2) Manufacturer code
Error code Error source Description
Channel No.
storage
destination
*1
Reference
300 to 399
GOT
*2
Error code of the GOT main unit
function
GS262
*3
■3. System alarm list
400 to 499
Error code of the GOT communication
function
500 to 699
Error code of the GOT main unit
function
800 to 999 Network Error code of network GS264
Error code Error source Description
Channel No.
storage
destination
*1
Reference
1 to 32767 Controller Error codes for the controller GS263 Manual of the controller
Identification code Description
GGOT error
N Network error (in the network unit that is mounted on the GOT)
M Mitsubishi controller error
C Non-Mitsubishi controller, microcomputer, or MODBUS error
Manufacturer code Description
01h Mitsubishi Electric Corporation
20h Computer, MODBUS
21h OMRON
22h KEYENCE
23h FUJI ELECTRIC (PLC)
