11.5 Ethernet Check

■1. Ethernet check function

The Ethernet status check function sends a ping to check the connection status of Ethernet.

■2. Display operation of Ethernet check

Ethernet Check

Touch

[Comm.

ettings].

Main menu

Communication settings

Touch

[Ethernet check].

( 9.3 Utility Display)
