7.3 BootOS and System Application Installation Using Data Storage
7 - 5
7
INSTALLATION OF BOOTOS AND BASIC SYSTEM APPLICATION
7.3.1 Installing when starting the GOT
The displayed message is different depending on the installation condition of the basic system application in the GOT. When
the screen requesting operation is displayed, operate the GOT according to the instructions on the screen.
POINT
POINT
POINT
S.MODE switch-pressing installation function
When the data storage that stores data with the OS boot drive set to the A drive is used, the
S.MODE switch-pressing installation function is not available.
■1. Operation procedure
The S.MODE switch is on the back of the GOT, as shown below.
(1) When installing with an SD card
Step 1.
Power OFF the GOT, and install the SD card where the BootOS, system application or project data is
stored in the SD card interface of the GOT.
Step 2. Close the cover of the SD card interface of the GOT.
Step 3. Power on the GOT.
Power on the GOT while pressing the install switch (S.MODE switch) on the back of the GOT. (1-point
press installation function)
Step 4. The BootOS or system application is installed in the built-in flash memory.
The SD card access LED is lit during the install execution.
Do not pull out the SD card or power OFF the GOT while the SD card access LED is lit.
Installation switch
(S.MODE)
Now installing BootOS.
