7 - 6
7.3 BootOS and System Application Installation Using Data Storage
Step 5. The GOT restarts automatically after the installation is completed.
(When the system application is already installed, the GOT restarts by touching the button)
Step 6. After confirming normal restart, confirm that the SD card access LED is not lit, and remove the SD card
from the SD card interface of the GOT.
(2) When installing with USB memory
Step 1.
Power off the GOT, and install the USB memory where the BootOS, system application or project data is
stored in the USB interface of the GOT.
The BootOS cannot be stored in the USB memory where the system application or project data is stored.
Step 2. Power on the GOT.
Power on the GOT while pressing the install switch (S.MODE switch) on the back of the GOT. (1-point
press installation function)
Step 3. The BootOS or system application is installed in the built-in flash memory.
The USB memory access LED is lit during the installation execution.
Do not pull out the USB memory or power off the GOT while the USB memory access LED is lit.
Step 4. The GOT restarts automatically after the installation is completed.
(When the system application is already installed, the GOT restarts by touching the button)
Step 5. After confirming normal restart, confirm that the USB memory access LED is not lit, and remove the USB
memory from the USB interface of the GOT.
For removing methods of the USB memory, refer to the following.
âž 4.2.3 USB device status display operation
