16.2 FX List Editor (GT2104-R only)
16 - 33
GOT SELF CHECK (DEBUG)
16
16.2.15 Parameter setting
Sets FX PLC parameters.
■1. Parameters that can be changed and change targets
(1) Parameters that can be changed
The parameters that can be changed with the MELSEC-FX list editor and the target FX PLCs are as follows.
: Can be set/changed : Cannot be set/changed
*1 When connecting an FX0(S), set "0". Setting other than "0" causes a parameter error.
*2 When the parameters are initialized, the display on the MELSEC-FX list editor is different from the FX PLC default values, but do
not change the latch range. Changing the latch range causes an error.
(2) Change targets
When a memory cassette is mounted, the parameters in the memory cassette are targeted for changes.
■2. Operation
*1 When checking parameters (not changing), it is not necessary to stop the PLC.
Item
Target CPU
FX0(S)
/FX0N
FX1 FX2(C) FX1S FX1N(C) FX2N(C) FX3S FX3G(C) FX3U(C)
Memory space
setting
File register space
setting
*1
Latch range setting
*2 *2 *2
RUN terminal setting
Initialization of
parameters
Stop the FX PLC
[Parameter setting] OP GO
*1
OP
GO
Select [Parameter setting] with or .
*1
Stop the FX PLC
To Next Page
