2 - 20
2.6 Operation
2.6 Operation
2.6.1 Operation setting
Setting regarding GOT operation can be set.
The items which can be set are described below. If touch the each item part, the respective setting becomes possible.
*1 Relation between the [Key sensitivity] setting and reaction speed
The larger the set value in [Key sensitivity] is, the shorter the time taken from touching the touch panel until the GOT responds
becomes. E.g. decrease the value set for [Key sensitivity] when double-touch is made when touching the GOT screen only once.
(Decrease the reaction speed.)
Operation setting by GT Designer3
Set buzzer volume and window move buzzer volume by [GOT setup] in [Environmental Setting]
of GT Designer3.
When change a part of the setting, change the setting by the GOT display setting after
downloading the project data.
➠ GT Designer3 (GOT2000) Help
Function Description Setting range
Buzzer volume setting Buzzer volume setting can be changed.
OFF/SHORT/LONG
<At factory shipment: SHORT>
Musical interval setting The setting of the musical interval for the buzzer sound can be changed.
1 to 5
<Default: 4>
Window move buzzer volume setting Whether turn ON/OFF buzzer when move window can be selected.
ON/OFF
<At factory shipment: OFF>
Key sensitivity setting
The touch panel sensitivity when touching the GOT screen can be set.
E.g. a setting can be changed when double-touch is made when
touching the GOT screen only once. (For preventing chattering)
1 to 8
*1
<Default: 6>
Access switch for the drive A
Set whether to access drive A or not while the cover of an SD card
interface is open.
Unignore/Ignore
<Default: Unignore>
To Next Page
