16.1 Device Monitor Function
16 - 1
GOT SELF CHECK (DEBUG)
16
16. GOT SELF CHECK (DEBUG)
The debug includes functions to check the PLC system status and to improve troubleshooting efficiency.
The following is available as the debug.
16.1 Device Monitor Function
For a controller connected to the GOT, forcibly turning on or off devices of the controller and changing the set value or
present value are available.
16.1.1 System configuration
This section describes the controller names and connection types between the GOT and a controller that are applicable to
the device monitor function.
For details of communication units and cables for each connection type, refer to the following manual.
➠ GOT2000 Series Connection Manual for GT Works3 Version1
■1. Target controller
■2. Required system application
POINT
POINT
POINT
Checking method of the version of basic system application and communication driver
Check the version of the basic system application and communication driver installed in the GOT
at [System Application Information] of the utility.
Refer to the following for details.
➠ 15.2 OS information
Item Description Reference
Device monitor
For a controller connected to the GOT, forcibly turning on or off devices of the controller and
changing the set value or present value are available.
➠ 16 - 1
FX3U-ENET-ADP
communication setting
function
The communication set value of the FX3U-ENET-ADP stored in the CPU can be changed.
➠ 16 - 40
Controller Connection type
QCPU (Q mode), LCPU Ethernet connection, Direct CPU connection, Computer link connection, CC-Link(G4) connection
QnACPU Direct CPU connection, Computer link connection
ACPU, QCPU (A mode) Direct CPU connection
FXCPU Ethernet connection, Direct CPU connection
Inverter Inverter connection
Microcomputer Microcomputer connection
MODBUS/RTU equipment MODBUS/RTU connection
System application Version
Basic system application -
Communication
driver
MELSEC-Q/L/QnA
-
MELSEC-A
MELSEC-FX -
CC-Link(G4)
-
FREQROL 500/700/800,
Sensorless servo
Microcomputer connection
MODBUS/RTU
