2 - 2
2.1 Display
2.1 Display
2.1.1 Display setting
Configure display settings.
The items which can be set are shown below. When each item part is touched, the respective setting becomes possible.
*1 If setting 0, the title screen is not hidden.
The title screen is always displayed for 4 seconds or longer (which changes depending on the project data contents).
*2 The monitoring time corresponding to the sensor detect level (0 to 10) is as follows.
As the sensor detect level becomes greater, the sensitivity of the human sensor becomes higher.
*3 For BootOS version D or earlier, the [Standard] mode is specified.
*4 For GT23, the brightness can be adjusted in 16 levels.
The following table shows the correspondences between values set in the utility and the brightness in 16 levels.
*5 GT23 does not support.
Item Description Setting range
Opening screen time The title display period at the main unit boot can be set.
0 to 60 seconds
*1
<At factory shipment: 0 seconds>
Screen save time
The period from the user stops the touch panel operation till the
screen save function starts can be set.
0 to 60 minutes
*1
<At factory shipment: 0 minutes>
Battery alarm display
Whether to display system alarm when the voltage of the GOT
internal battery has dropped can be specified.
ON/OFF
<At factory shipment: OFF>
Human sensor
Screen saver status cancel by human sensor can be set to
Effective or Invalid.
Valid/Invalid
<At factory shipment: Invalid>
Sensor detect level
*2
The sensor detect level can be set.
0 to 10
<At factory shipment: 10>
Sensor detect time
*2
The time corresponding to the [Sensor detect level] is displayed.
(setting is disabled)
When the [Sensor detect level] is changed, the corresponding time
is reflected by touching [OK] button.
0 to 4
<At factory shipment: 0 seconds>
Sensor off delay
The time period from when the human sensor detects no human
movement until the Human Sensor Detection Signal (System
Signal 2-1.b5) turns OFF can be set.
0Min 10Sec to 60Min 0Sec
<At factory shipment: 0Min 10Sec>
Brightness adjustment mode
*3
The brightness adjustment mode can be set to the standard or low
intensity mode.
Standard/Low
<At factory shipment: standard>
Brightness adjustment The brightness can be adjusted.
1 to 32
*4
<Default: 32>
POWER LED
*5
Turning on/off the POWER LED can be set.
Turning on/off
<At factory shipment: turning on>
Sensor detect level 109876543210
Sensor detect time [s] 0 0.1 0.2 0.4 0.8 1 1.5 2 2.5 3 4
Setting value 1 2 3 4 5 6 7 8 ··· 2526272829303132
Brightness adjustment (16
levels)
1234···13141516
