16.2 FX List Editor (GT2104-R only)

16 - 13

GOT SELF CHECK (DEBUG)

16.2 FX List Editor (GT2104-R only)

The MELSEC-FX list editor can change the sequence programs on the FX PLC.

16.2.1 Display operation of FX list editor

Main menu

Cannel Setting

FX list editor

Debug

Touch

[FX list editor].

Touch [Debug].
