15.1 Data Storage Location
15 - 1
CONTROL OF VARIOUS DATA (DATA CONTROL)
15
15. CONTROL OF VARIOUS DATA (DATA CONTROL)
A system application, project data (screen data), or alarm data which is written in the GOT or SD card can be displayed, and
the data can be transferred between the GOT and SD card.
The format of the SD card is also possible.
15.1 Data Storage Location
15.1.1 Data type and storage location
■1. System
The data storage location and transferring (write/read) route for each data type are shown below.
Also, the data storage locations are shown below.
*1 An SD card unit (GT21-03SDCD) which is sold separately is required.
The data of the built-in flash memory (Project data, etc.) can be saved even if the battery voltage becomes low.
*1 The SD card can be used from Utility.
➠ 15.2 OS information
*2 When using the project data stored in the Standard SD Card (A drive) with the GOT, hold the SD card installed to the GOT.
Item Data type Storage location
BootOS Built-in flash memory (C drive)
*1
Basic system application
Standard SD card (A drive)
Built-in flash memory (C drive)
*2
Communication driver
Advanced system application
*1
Project data
(Including recipe setting, alarm conditions, time action, and GOT setup.)
Standard SD card (A drive)
Built-in flash memory (C drive)
*2
Read
Upload
Write
Write
Install/
Download
PC
GT Designer3
A drive
*1
(Standard SD card)
SD card
(when installed in GOT)
Inserting/
Removing
SD card
(when installed in PC)
C drive
(Built-in flash memory)
Copy files on Windows
System application
BootOS
Project data
Project data
Project data
Project data
Install, Write:
Upload, Read:
BootOS
System application
BootOS
System application
Project data
BootOS
Project data
®
BootOS
System application
Project data
