4.6 Drawing Check
4 - 17
4
MAINTENANCE
(c) Pattern 3: Shape transformation, color check
The overlapped shapes of pattern 1 and pattern 2 are displayed.
If the shape and color are displayed visually in order, it is normal.
(d) Pattern 4: Shape check
The drawn figures are displayed in order and at regular intervals.
If the shape and color are displayed visually in order, it is normal.
If touch the upper right part of the screen, returns to [Display check] screen.
To Pattern 4
To [Display check]
The main screen image after the screen information read and write is executed
