15 - 22
15.3 Resource Data Information
■3. Example of logging information display
No. Item Description
(1) Drive selection
The target drive can be selected. (Even if an SD card is not installed, this message
appears.)
(2) Kind
Indicates whether the displayed name is file or folder.
Displays the extension for a file and "DIR" for a folder.
(3) Name
Displays the file name or folder name.
For the long file/folder name, entire part may not be displayed.
(4) Size Displays the size of the file displayed in Name.
(5) Date, Time Displays the creation date and time of each file.
(6) Operation switch Execution switch of each function.
Logging information screen
Storage file/folder display screen
Logging information screen
(1)
(3) (4)
(2)
(5)
(6)
