Mitsubishi MELSEC iQ-F FX5 series - Setting Annunciator

116
5 SEQUENCE INSTRUCTIONS
5.3 Output Instructions
Setting annunciator
SET F
This instruction turns ON the specified annunciator.
Setting data
■Descriptions, ranges, and data types
■Applicable devices
*1 Only F can be used.
Processing details
• This instruction turns ON the annunciator specified by (d) when the execution command turns ON.
• Operation is as follows when annunciator (F) is turned ON.
• When the content of SD63 is 16 (16 annunciators are already ON), the annunciator number that turns ON is not stored in
SD64 to SD79 even if a new annunciator turns ON.
Operation error
There is no operation error.
Ladder diagram Structured text
ENO:=SET(EN,d);
Operand Remarks Range Data type Data type (label)
(d) Annunciator number (F number) that is set  Bit ANY_BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(d) 
*1
        
• The annunciator number (F number) that turns ON is stored in special registers (SD64 to SD79).
• The content of SD63 is incremented by 1.
(d)
SD63
SD64
SD65
SD66
SD78
SD79
SD63
SD64
SD65
SD66
SD78
SD79
16
233
90
700
145
1027
16
233
90
700
145
1027
Does not change.
F30 is turned ON.
