18 BIT SHIFT FUNCTIONS
18.1 n-bit Left Shift
791
18
18 BIT SHIFT FUNCTIONS
18.1 n-bit Left Shift
SHL(_E)
These functions shift an input value leftward by (n) bits and output the result.
Setting data
■Descriptions, types, and data types
Processing details
■Operation processing
• These functions shift the WORD or DWORD type data input to (s) left by (n) bits and output the result in the same data type
as (s) from (d).
• The number input in (n) is used as the number of left-shift bits.
Ex.
When the data type of (s) is WORD and 8 is input in (n)
• "0" is set to "n" bits from the least significant bit.
• A value input to (n) is the WORD or DWORD type data value.
• A value input to (n) (Number of shift bits) is the INT type data value and within the following range.
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=SHL(s,n);
[With EN/ENO]
d:=SHL_E(EN,ENO,s,n);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable ANY_BIT
n Number of shift bits Input variable ANY_BIT
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable ANY_BIT
When the data type of (s) is WORD When the data type of (s) is DWORD
A value in (n) is within 0 to 15.
The lower 4-bit data of the value in (n) is used.
[Example]
When the input value is 6: 6
When the input value is 22: 6
A value in (n) is within 0 to 31.
The lower 5-bit data of the value in (n) is used.
[Example]
When the input value is 6: 6
When the input value is 22: 22
s d
n
EN ENO
sd
n
IN (WORD)
270FH F00H
WORD
0100100011100111
270FH
01110 10000000000
F00H
These bits become "0".
