Mitsubishi MELSEC iQ-F FX5 series User Manual

194
6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
Adding BCD 8-digit data
DB+(P) [using two operands]
These instructions add the BCD 8-digit data in the device specified by (d) and the BCD 8-digit data in the device specified by
(s), and store the result in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions add the BCD 8-digit data in the device specified by (d) and the BCD 8-digit data in the device specified
by (s), and store the addition result in the device specified by (d).
• If the addition result exceeds 99999999, carry is ignored. In this case, the carry flag (SM700) does not turn ON.
Operation error
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s) Addend data or the head device where the data that is
added to another is stored
0 to 99999999 BCD 8-digit ANY32
(d) Head device where the data to which another is added is
stored
0 to 99999999 BCD 8-digit ANY32
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)       
(d)       
Error code
(SD0/SD8067)
Description
3405 BCD data in the device specified by (s) is outside of the valid range (0 to 99999999).
BCD data in the device specified by (d) is outside of the valid range (0 to 99999999).
(s) (d)
(d)(d)+1 (s)(s)+1 (d)(d)+1
+
0032345690871068 01 194524
0 is entered.
(Upper 4 digits) (Lower 4 digits)(Upper 4 digits) (Lower 4 digits) (Upper 4 digits) (Lower 4 digits)
1065432199000000 00 654321
+
