6 BASIC INSTRUCTIONS
6.5 Data Conversion Instructions
267
6
Converting 32-bit binary data to Gray code
DGRY(P)(_U)
These instructions convert the 32-bit binary data in the device specified by (s) to 32-bit binary gray code data, and store the
converted data in the device specified by (d).
■Descriptions, ranges, and data types
■Applicable devices
• These instructions convert the 32-bit binary data in the device specified by (s) to 32-bit binary gray code data, and store the
converted data in the device specified by (d).
The data conversion speed depends on the scan time of the CPU module.
There is no operation error.
Ladder diagram Structured text
ENO:=DGRY(EN,s,d);
ENO:=DGRYP(EN,s,d);
ENO:=DGRY_U(EN,s,d);
ENO:=DGRYP_U(EN,s,d);
Operand Description Range Data type Data type (label)
(s) DGRY(P) Binary data or the head device where the binary
data is stored
0 to 2147483647 32-bit signed binary ANY32_S
DGRY(P)_U 0 to 4294967295 32-bit unsigned binary ANY32_U
(d) DGRY(P) Head device for storing the gray code data after
conversion
32-bit signed binary ANY32_S
DGRY(P)_U 32-bit unsigned binary ANY32_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)
(d)
(s) BIN
(d)
0
305419896
001 0 0 1 0 0 0 1 1 0 1 0 0 0 1 0 1 0 1 1 0 0 1 1 1 1 0 00
b31 b16 b0b15
0
305419896
001 1 0 1 1 0 0 1 0 1 1 1 0 0 1 1 1 1 1 0 1 0 1 0 0 0 1 00
(d)+1
b31 b16 b0b15
(d)
···
···
···
···
Gray code
(s)+1 (Upper 16 bits) (s) (Lower 16 bits)
