Mitsubishi MELSEC iQ-F FX5 series - Twos Complement of 16-Bit Binary Data (Sign Inversion)

282
6 BASIC INSTRUCTIONS
6.5 Data Conversion Instructions
Two's complement of 16-bit binary data (sign inversion)
NEG(P)
These instructions invert the sign of the 16-bit binary data in the device specified by (d), and store the resultant data in the
device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions invert the sign of the 16-bit binary data in the device specified by (d), and store the resultant data in the
device specified by (d).
• They are used when a positive or negative sign is to be inverted.
Precautions
Note that data is inverted in every operation cycle in a continuous operation type (NEG) instruction.
Operation error
There is no operation error.
Ladder diagram Structured text
ENO:=NEG(EN,d);
ENO:=NEGP(EN,d);
Operand Description Range Data type Data type (label)
(d) Head device for storing the data that performs two's
complement
-32768 to +32767 16-bit signed binary ANY16
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(d)       
(d)
1
(d)
(d)
···b15 b0
101 10 0101 10 01010
···b15 b0
010 01 1 010 01 10110
101 10 0101 10 01010
000 00 0000 00 00000
-
··· -21846
··· 21846
Before execution
Sign conversion
After execution
16 bits
