Page #702 background imageLoading...
Page #702 background image
700
15 TYPE CONVERSION FUNCTIONS
15.11 Converting WORD to TIME
15.11 Converting WORD to TIME
WORD_TO_TIME(_E)
These functions convert WORD type data to TIME type data.
Setting data
â– Descriptions, types, and data types
Processing details
â– Operation processing
• These functions convert the WORD type data input to (s) to TIME type data and output from (d).
• A value input to (s) is the WORD type data value.
â– Operation result
1. Function without EN/ENO
The operation processing is executed. The operation output value is output from (d).
2. Function with EN/ENO
The following table lists the execution conditions and operation results.
*1 When FALSE is output from ENO, data output from (d) is undefined. In that case, modify a program so that the data output from (d) is
not used.
Operation error
There is no operation error.
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=WORD_TO_TIME(s);
[With EN/ENO]
d:=WORD_TO_TIME_E(EN,ENO,s);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable WORD
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable TIME
Execution condition Operation result
EN ENO (d)
TRUE (Executes operation) TRUE Operation output value
FALSE (Stops operation) FALSE
*1
Indefinite value
sd
EN ENO
ds
WORD
1234H
0H
TIME
T#1s234ms
T#0ms
(s)
(d)
