Mitsubishi MELSEC iQ-F FX5 series User Manual

APPENDIX
Appendix 1 Number of Instruction Steps
857
A
APPENDICES
Appendix 1 Number of Instruction Steps
The number of instruction steps are shown below.
The number of steps may increase depending on the contents of the source and destination (such as specification of BFM or
character string), bit specification of word device, nibble specification of bit devices, indexing etc.
Instruction name Number of minimum steps
LD 2
LDI 2
AND 2
ANI 2
OR 2
ORI 2
LDP 4
LDF 4
ANDP 4
ANDF 4
ORP 4
ORF 4
LDPI 4
LDFI 4
ANDPI 4
ANDFI 4
ORPI 4
ORFI 4
ANB 1
ORB 1
MPS 1
MRD 1
MPP 1
INV 1
MEP 3
MEF 3
OUT 2
OUT T/ST 5
OUTH T/ ST 5
OUTHS T/ST 5
OUT C 5
OUT LC 5
OUT F 3
SET 2
RST 2
SET F 3
RST F 3
ANS 7
ANR 1
ANRP 1
PLS 3
PLF 3
FF 3
ALT 3
