6 BASIC INSTRUCTIONS
6.6 Data Transfer Instructions
305
6
Transferring identical 16-bit block data (65535 points maximum)
FMOV(P)
These instructions transfer (n) point(s) of data identical to the 16-bit binary data in the device specified by (s) to the devices
specified by (d).
■Descriptions, ranges, and data types
■Applicable devices
• These instructions transfer (n) point(s) of data identical to the 16-bit binary data in the device specified by (s) to the device
specified by (d).
• If the number of points specified by (n) exceeds the device number range, data is transferred within the possible range.
• When a constant (K) is specified as the transfer source (s), it is automatically converted into binary.
When the value specified in (n) is 0, an operation error does not occur, but no processing is performed,
There is no operation error.
Ladder diagram Structured text
ENO:=FMOV(EN,s,n,d);
ENO:=FMOVP(EN,s,n,d);
Operand Description Range Data type Data type (label)
(s) Data to be transferred or the head device for storing the
data to be transferred
-32748 to +32767 16-bit signed binary ANY16
(d) Head device of the transfer-destination 16-bit signed binary ANY16
(n) Number of transfers 1 to 65535 16-bit unsigned binary ANY16
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)
(d)
(n)
···
(n)
3456H
3456H
3456H
3456H
3456H
3456H
b15 b0
(s)
(d)
(d)+1
(d)+2
(d)+(n-2)
(d)+(n-1)
···
b15 b0···
Transferred
