15 TYPE CONVERSION FUNCTIONS
15.52 Converting DINT to Bit Array
15.52 Converting DINT to Bit Array
DINT_TO_BITARR(_E)
These functions output low-order (n) bits of DINT type data to a bit array.
â– Descriptions, types, and data types
â– Operation processing
• These functions output low-order (n) bits of ANY 32 type data specified to (s) to (d).
• Output bits beyond the specified number of bits are not changed.
â– Operation result
1. Function without EN/ENO
The operation processing is executed. The operation output value is output from (d).
2. Function with EN/ENO
The following table lists the execution conditions and operation results.
*1 When FALSE is output from ENO, data output from (d) is undefined. In that case, modify a program so that the data output from (d) is
not used.
There is no operation error.
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=DINT_TO_BITARR(s,n);
[With EN/ENO]
d:=DINT_TO_BITARR_E(EN,ENO,s,n);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable ANY32
n Only a constant 4, 8, 12, 16, 20, 24, 28 or 32 can be specified. Input variable BOOL
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output (Variables are available for element specification.) Output variable BOOL array element
Execution condition Operation result
EN ENO (d)
TRUE (Executes operation) TRUE Operation output value
FALSE (Stops operation) FALSE
*1
Indefinite value
