Mitsubishi MELSEC iQ-F FX5 series User Manual

754
15 TYPE CONVERSION FUNCTIONS
15.48 Converting STRING to TIME
15.48 Converting STRING to TIME
STRING_TO_TIME(_E)
These functions convert STRING type data to TIME type data.
Setting data
■Descriptions, types, and data types
Processing details
■Operation processing
• These functions convert the STRING type data input to (s) to TIME type data and output from (d).
• A value input to (s) is the STRING type data value.
■Operation result
1. Function without EN/ENO
The operation processing is executed. The operation output value is output from (d).
2. Function with EN/ENO
The following table lists the execution conditions and operation results.
*1 When FALSE is output from ENO, data output from (d) is undefined. In that case, modify a program so that the data output from (d) is
not used.
Operation error
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=STRING_TO_TIME(s);
[With EN/ENO]
d:=STRING_TO_TIME_E(EN,ENO,s);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable STRING(11)
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable TIME
Execution condition Operation result
EN ENO (d)
TRUE (Executes operation) TRUE Operation output value
FALSE (Stops operation) FALSE
*1
Indefinite value
Error code
(SD0/SD8067)
Description
3401 Values for each place of the ASCII code for input are other than "30H" to "39H", "20H", and "00H".
Value of the ASCII code for input are outside the following range.
-2147483648 to 4147483647
sd
EN ENO
ds
STRING
'01234567'
'00000000'
TIME
T#20m34s567ms
T#0ms
(s) (d)
