6 BASIC INSTRUCTIONS
6.3 Logical Operation Instructions
217
6
Performing an AND operation on 32-bit data
DAND(P) [using two operands]
These instructions AND each bit of 32-bit binary data from the device specified by (d) and each bit of 32-bit binary data from
device specified by (s), and store the results in the device specified by (d).
■Descriptions, ranges, and data types
■Applicable devices
• These instructions AND each bit of 32-bit binary data from the device specified by (d) and each bit of 32-bit binary data from
device specified by (s), and store the results in the device specified by (d).
• Bit devices subsequent to number of points by nibble specification are calculated as 0.
There is no operation error.
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s) Data for AND or head device where the data is stored -2147483648 to +2147483647 32-bit signed binary ANY32
(d) Head device for storing AND results -2147483648 to +2147483647 32-bit signed binary ANY32
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)
(d)
(d)
(d)
(s)
···
···
···
···
···
···
b31
b31
b31
b16
b16
b16
b15
b15
b15 b0
b0
b0
AND
1111 1100 110011
0101 1001 100001
0101 1 000 10 0 001
(d)+1 (d)
(s)+1 (s)
(d)+1 (d)
