Mitsubishi MELSEC iQ-F FX5 series User Manual

3 MODULE SPECIFIC INSTRUCTION
3.1 High-speed Counter Instruction
79
3
3 MODULE SPECIFIC INSTRUCTION
3.1 High-speed Counter Instruction
High-speed processing instruction
■Setting 32-bit data comparison
■Reset 32-bit data comparison
■Comparison of 32-bit data band
■Start/stop of the 16-bit/32-bit data high-speed I/O function
High-speed current value transfer instruction
■High-speed current value transfer of 16-bit/32-bit data
3.2 External Device I/O Instruction
Serial communication 2
Instruction symbol Description Reference
DHSCS Turns ON the bit device of (d) when the current value of the high-speed counter of CH specified by
(s2) is changed to the value specified by (s1).
Page 634
Instruction symbol Description Reference
DHSCR Turns OFF the bit device of (d) when the current value of the high-speed counter of CH specified
by (s2) is changed to the value specified by (s1).
Page 636
Instruction symbol Description Reference
DHSZ Compares whether the current value of the high-speed counter is within or outside the value range
specified by (s1) or (s2).
Page 638
Instruction symbol Description Reference
HIOEN Start or stop high-speed I/O for the specified CH. Page 640
HIOENP
DHIOEN Page 642
DHIOENP
Instruction symbol Description Reference
HCMOV Transfers the current value of the high-speed I/O. Page 644
HCMOVP
DHCMOV Page 646
DHCMOVP
Instruction symbol Description Reference
RS2 Sends/receives data by non-protocol communication. Page 648
