11 POSITIONING INSTRUCTION
11.1 Positioning Instruction
657
11
Positioning by one table operation
TBL [For the FX3 Series-compatible operand specification]
This instruction executes one specified table operation from the instructions set in the data table using the engineering tool
etc.
■Descriptions, ranges, and data types
■Applicable devices
*1 Only Y can be used.
This instruction operates one table of the positioning table that is set with parameters in the engineering tool.
• For (d), specify the device from which pulses are output. Only the output devices (Y) having positioning parameters can be
specified.
• For (n), specify the table number to be executed according to the output specified in (d).
For details on the function, precautions, and error code, refer to Built-in positioning manual.
Ladder diagram Structured text
ENO:=TBL(EN,n,d);
Operand Description Range Data type Data type (label)
(d) Bit device number (Y) from which pulses are output 0 to 3 Bit ANY_ELEMENTARY
(n) Table number to be executed 1 to 100 16-bit unsigned binary ANY16_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(d)
*1
(n)
To Next Page
