118
5 SEQUENCE INSTRUCTIONS
5.3 Output Instructions
Setting annunciator (with check time)
ANS
This instruction sets the annunciator (F device).
■Descriptions, ranges, and data types
■Applicable devices
*1 Only T can be used.
*2 Only F can be used.
• This instruction sets (d) when the command input remains ON continuously for the evaluation time [(m)100 ms, (s)] or
more. This instruction resets the current value of (s) evaluation timer and does not set (d) when the command time is less
than the evaluation time [(m)100 ms]. Also, this instruction resets the evaluation timer when the command input turns
OFF.
■Related devices
There is no operation error.
Ladder diagram Structured text
ENO:=ANS(EN,s,m,d);
Operand Remarks Range Data type Data type (label)
(s) Timer number for evaluation time 16-bit signed binary ANY16
(m) Evaluation time data 1 to 32767 16-bit unsigned binary ANY16_U
(d) Annunciator device to be set Bit ANY_BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)
*1
(m)
(d)
*2
Device Name Remarks
SM8049 ON status annunciator smallest number
enabled
When SM8049 is turned ON, SM8048 and SD8049 are enabled.
SM8048 Annunciator operation When one of the F devices is operating, SM8048 turns ON.
SD8049 ON status annunciator smallest number The smallest number of the F devices that are operating is stored.
ANS (s) (m) (d)
(d)
Command input
Command input
((m) less than 100 ms) ((m) 100 ms or more)
Equivalent to or longer
than the evaluation time
Less than the evaluation
time
To Next Page
