Mitsubishi MELSEC iQ-F FX5 series User Manual

260
6 BASIC INSTRUCTIONS
6.5 Data Conversion Instructions
Converting 32-bit signed binary data to 16-bit signed binary data
DINT2INT(P)
These instructions convert the 32-bit signed binary data in the device specified by (s) to 16-bit signed binary data, and store
the converted data in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions convert the 32-bit signed binary data in the device specified by (s) to 16-bit signed binary data, and store
the converted data in the device specified by (d).
Operation error
There is no operation error.
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s) Data before conversion  32-bit signed binary ANY32_S
(d) Data after conversion  16-bit signed binary ANY16_S
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)       
(d)       
(s) (d)
SM402
M0
b31 b16
(-1737075662)
5432H
9876HD1, D0
(d)
b15 b0
(21554)
5432HD100
(s)
b15 b0
∙∙∙ ∙∙∙ ∙∙∙
(s) (d)
DMOVP
H98765432 D0
DINT2INT D0 D100
Before conversion After conversion
Stores in lower 16 bits
