Mitsubishi MELSEC iQ-F FX5 series User Manual

6 BASIC INSTRUCTIONS
6.5 Data Conversion Instructions
251
6
Converting single-precision real number to 16-bit unsigned
binary data
FLT2UINT(P)
These instructions convert the single-precision real number in the device specified by (s) to 16-bit unsigned binary data, and
store the converted data in the device specified by (d). After conversion, the first digit after the decimal point of the single-
precision real number is rounded off.
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions convert the single-precision real number in the device specified by (s) to 16-bit unsigned binary data,
and store the converted data in the device specified by (d). After conversion, the first digit after the decimal point of the
single-precision real number is rounded off.
Operation error
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s) Data before conversion 0 to 65535 Single-precision real
number
ANYREAL_32
(d) Data after conversion  16-bit unsigned binary ANY16_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)   
(d)       
Error code
(SD0/SD8067)
Description
3401 The single-precision real number in the device specified by (s) is out of the valid range (0 to 65535).
3402 When the contents of the specified device are outside the following range:
0, 2
-126
|specified value (stored value)|<2
128
The specified device value is -0, denormalized number, NaN (not a number), or .
(s) (d)
SM402
M0
(d)
(1235)
04D3H
b15 b0
D100
(s)
b31 b16
(1234.5)
5000H
449AH
b15 b0
D1, D0
∙∙∙ ∙∙∙ ∙∙∙
(s) (d)
EMOVP
E-1234.5 D0
FLT2UINT D0 D100
After conversion
Before conversion
