Mitsubishi MELSEC iQ-F FX5 series User Manual

7 APPLICATION INSTRUCTION
7.7 Real Number Instruction
463
7
Searching the minimum value of single-precision real number
EMIN(P)
These instructions search for the minimum value in the (n) point(s) of single-precision real number block data in the device
starting from the one specified by (s), and store the minimum value in the device areas specified by (d) and (d)+1.
These instructions also store the location of the first minimum value from (s) in the device specified by (d)+2 and the number
of minimum values in the device specified by (d)+3.
*1 The EMIN instruction is not supported by the ST language. Use MIN of the standard function.
Page 804 MAX(_E), MIN(_E)
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions search for the minimum value in the (n) point(s) of single-precision real number block data in the device
starting from the one specified by (s), and store the minimum value in the device areas specified by (d) and (d)+1. These
instructions also store the location of the first minimum value from (s) in the device specified by (d)+2 and the number of
minimum values in the device specified by (d)+3.
• The start of the block data in the device specified by (s) is counted as 1st point when the location is counted.
• The following values are stored in (d).
• When (n) is 0, the processing is not performed.
Ladder diagram Structured text
*1
ENO:=EMINP(EN,s,n,d);
Operand Description Range Data type Data type (label)
(s) Search target data  Single-precision real number Single-precision real number
(d) Search result  Single-precision real number Single-precision real number
(n) Number of search target data points  16-bit unsigned binary ANY16
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)       
(d)       
(n)       
Data type Description
(d) Single-precision real number Minimum value
(d)+1
(d)+2 16-bit data Minimum value position
(d)+3 16-bit data Number of minimum values
(s) (d) (n)
1.2345
123.45
-1.2345
-12.345
-123.45
(s)+1, (s)
(s)+3, (s)+2
(s)+5, (s)+4
(d)+1, (d)
(d)+2
(d)+3
(s)+7, (s)+6
(s)+9, (s)+8
(n)
-123.45
2
1
Minimum value
Position
Number of data
