764
16 SINGLE NUMBER VARIABLE FUNCTIONS
16.1 Absolute Value
16 SINGLE NUMBER VARIABLE FUNCTIONS
16.1 Absolute Value
ABS(_E)
These functions output the absolute value of an input value.
â– Descriptions, types, and data types
â– Operation processing
• These functions output the absolute value of the INT, DINT, or REAL type data input to (s) in the same data type as (s) from
(d).
• These functions are expressed as follows when the input value is "A" and the output operation result is "B".
• A value input to (s) is the INT, DINT, or REAL type data value.
• When -32768 is input while the data type of (s) is INT, -32768 is output from (d).
• When -2147483648 is input while the data type of (s) is DINT, -2147483648 is output from (d). (An operation error does not
occur. "ABS_E" outputs "TRUE" from output variable ENO.)
â– Operation result
1. Function without EN/ENO
The following table lists the operation results.
2. Function with EN/ENO
The following table lists the execution conditions and operation results.
*1 When FALSE is output from ENO, data output from (d) is undefined. In that case, modify a program so that the data output from (d) is
not used.
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=ABS(s);
[With EN/ENO]
d:=ABS_E(EN,ENO,s);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable ANY_NUM
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable ANY_NUM
B=|A|
Operation result (d)
No operation error occurred Operation output value
An operation error occurred Indefinite value
Execution condition Operation result
EN ENO (d)
TRUE (Executes operation) TRUE (Operation error did not occur) Operation output value
FALSE (Operation error occurred)
*1
Indefinite value
FALSE (Stops operation) FALSE
*1
Indefinite value
To Next Page
