Reading clock data
TRD(P)
These instructions read the clock data from the built-in real time clock in the CPU module.
■Descriptions, ranges, and data types
■Applicable devices
• These instructions read the clock data (SD210 to SD216) from the built-in real time clock in the CPU module to the device
numbers (d) to (d)+6 in the following format.
• The table below shows the related devices. The clock data stored in these special registers is updated during the END
processing.
Ladder diagram Structured text
ENO:=TRD(EN,d);
ENO:=TRDP(EN,d);
Operand Description Range Data type Data type (label)
(d) Head device number where the read clock data is stored 16-bit signed binary ANY16
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(d)
Device Item Clock data Device Item
Special
registers
SD210 Year 1980 to 2079 (year, four digits) D0 Year
SD211 Month 1 to 12 D1 Month
SD212 Day 1 to 31 D2 Day
SD213 Hour data 0 to 23 D3 Hour data
SD214 Minute data 0 to 59 D4 Minute data
SD215 Second data 0 to 59 D5 Second data
SD216 Day-of-the-week data 0 (Sunday) to 6 (Saturday) D6 Day-of-the-week data
Device Name Description
Binary code
SD210 Binary clock data (year) The year data in the clock data is stored as a four-digit binary code.
SD211 Binary clock data (month) The month data in the clock data is stored as a binary code.
SD212 Binary clock data (day) The day data in the clock data is stored as a binary code.
SD213 Binary clock data (hour) The hour data in the clock data is stored as a binary code.
SD214 Binary clock data (minute) The minute data in the clock data is stored as a binary code.
SD215 Binary clock data (second) The second data in the clock data is stored as a binary code.
SD216 Binary clock data (day of the week) The day-of-a-week data in the clock data (0: Sunday, 1: Monday, ..., 6: Saturday) is stored as a binary code.
Binary code (FX3 compatible area)
SD8013 Binary clock data (second) The second data in the clock data is stored as a binary code.
SD8014 Binary clock data (minute) The minute data in the clock data is stored as a binary code.
SD8015 Binary clock data (hour) The hour data in the clock data is stored as a binary code.
SD8016 Binary clock data (day) The day data in the clock data is stored as a binary code.
SD8017 Binary clock data (month) The month data in the clock data is stored as a binary code.
