Mitsubishi MELSEC iQ-F FX5 series

290
6 BASIC INSTRUCTIONS
6.5 Data Conversion Instructions
Connecting the specified number of bits
NUNI(P)
These instructions link each bit of the data in the device numbers specified by (s1) onwards into bit units specified by (s2), and
store the connected data in the device number specified by (d) onwards.
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Ladder diagram Structured text
ENO:=NUNI(EN,s1,s2,d);
ENO:=NUNIP(EN,s1,s2,d);
Operand Description Range Data type Data type (label)
(s1) Head device for storing the data to be linked  16-bit signed binary ANY16
(d) Head device for storing the linked data  16-bit signed binary ANY16
(s2) Head device for storing the link unit size  16-bit signed binary ANY16
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(d)       
(s2)       
(s1) (d) (s2)
