6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
177
6
Multiplying 16-bit binary data
*(P)(_U) instruction and MUL(P)(_U) instruction can be used for multiplication of 16-bit binary data.
*(P)(_U)
These instructions multiply the 16-bit binary data in the device specified by (s1) by the 16-bit binary data in the device
specified by (s2), and store the result in the device specified by (d).
■Descriptions, ranges, and data types
■Applicable devices
• These instructions multiply the 16-bit binary data in the device specified by (s1) by the 16-bit binary data in the device
specified by (s2), and store the multiplication result in the device specified by (d).
• When (d) is a bit device, lower-order bit is specified first.
Multiplication result when (d) is a bit device
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s1) *(P) Multiplicand data or the device where the data
to be multiplied by another is stored
-32768 to +32767 16-bit signed binary ANY16
*(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(s2) *(P) Multiplier data or the device where the data by
which another is to be multiplied is stored
-32768 to +32767 16-bit signed binary ANY16
*(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(d) *(P) Head device for storing the operation result 32-bit signed binary ANY32
*(P)_U 32-bit unsigned binary ANY32_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)
(s2)
(d)
• K1 ... Lower 4 bits (b0 to b3)
• K4 ... Lower 16 bits (b0 to b15)
• K8 ... Lower 32 bits (b0 to b31)
Error code
(SD0/SD8067)
Description
2820 The range of the device specified by (d) exceeds said device range.
b15 b0
5678 (BIN)
(s1) (s2)
1234 (BIN) 7006652 (BIN)
×
···
b15 b0
···
(d)
(d)+1
b0
··· ···
b31 b16 b15
