6 BASIC INSTRUCTIONS
6.3 Logical Operation Instructions
Performing an OR operation on 32-bit data
DOR(P) [using two operands]
These instructions OR each bit of 32-bit binary data from the device specified by (d) and each bit of 32-bit binary data from
device specified by (s), and store the results in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions OR each bit of 32-bit binary data from the device specified by (d) and each bit of 32-bit binary data from
device specified by (s), and store the results in the device specified by (d).
• Bit devices subsequent to number of points by nibble specification are calculated as 0.
Operation error
There is no operation error.
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s) Data for OR or head device where data is stored -2147483648 to +2147483647 32-bit signed binary ANY32
(d) Head device for storing the OR results -2147483648 to +2147483647 32-bit signed binary ANY32
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)       
(d)       
(s) (d)
···
···
···
···
···
···
b31
b31
b31
b16
b16
b16
b15
b15
b15 b0
b0
b0
OR
1111 0000 00 0011
1001 0001 11 0011
1111 0 001 11 0 011
(d)+1 (d)
(s)+1 (s)
(d)+1 (d)
(d)
(d)
(s)
