Mitsubishi MELSEC iQ-F FX5 series

836
23 TIME DATA FUNCTIONS
23.4 Division
23.4 Division
DIV_TIME(_E)
These functions output the quotient of input values (TIME data) ((s1)  (s2)).
Setting data
■Descriptions, types, and data types
Processing details
■Operation processing
• These functions divide the TIME type data input to (s1) and (s2) ((s1)  (s2)), and output the operation result from (d) as
TIME type data. The remainder is ignored.
Ex.
When a value input to (s1) and (s2) is T#1d2h33m44s55ms (1 day 2 hours 33 minutes 44 seconds 55 milliseconds) and 2
• A value input to (s1) is the TIME type data value.
• A value input to (s2) is the INT, DINT, or REAL type. (However, input other than 0 to (s2).)
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=DIV_TIME(s1,s2);
[With EN/ENO]
d:=DIV_TIME_E(EN,ENO,s1,s2);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s1 Input Input variable TIME
s2 Input Input variable ANY_NUM
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable TIME
s1 d
s2
EN ENO
ds1
s2
TIME
T#1d2h33m44s55ms
TIME
T#13h16m52s27ms
(d)
INT
2
(s2)(s1)

(Quotient) (Remainder)
T#1ms
Ignored
