676
12 INVERTER COMMUNICATION INSTRUCTION
12.2 Inverter operations control(Drive)
12.2 Inverter operations control(Drive)
IVDR
This instruction writes a control value necessary for inverter operation to a CPU module using the computer link operation
function of the inverter.
■Descriptions, ranges, and data types
*1 Refer to Serial communication manual or respective inverter manual.
■Applicable devices
*1 T, ST, C cannot be used.
The control value specified in (s3) is written to the instruction code specified in (s2) of an inverter connected to the channel to
be used (n) whose station number is specified in (s1). For details, refer to Serial communication manual. (For the
instruction codes, refer to the each inverter manual.)
Three devices are occupied from the device specified in (d). Make sure that these devices are not used in other controls.
For communication errors, refer to Serial communication manual.
Ladder diagram Structured text
ENO:=IVDR(EN,s1,s2,s3,n,d);
Operand Description Range Data type Data type (label)
(s1) Inverter station number K0 to 31 16-bit signed binary ANY16
(s2) Inverter instruction codes
*1
16-bit signed binary ANY16
(s3) Set value to be written to the inverter parameter or device number storing the
data to be set
16-bit signed binary ANY16
(n) Channel to be used K1 to 4 16-bit unsigned binary ANY16_U
(d) Head bit device to which the execution status of the instruction is output Bit ANY_BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)
*1
(s2)
*1
(s3)
(n)
(d)
*1
Error code
(SD0/SD8067)
Description
1810 Channel number specified by (d) is used by another instruction.
2820 The specified device exceeds the range of the corresponding device.
3405 The value specified by (s1) is other than any of K0 to 31.
The value specified by (n) is other than any of K1 to 4.
3600 Channel number specified by (d) is not set by parameters.
To Next Page
