Mitsubishi MELSEC iQ-F FX5 series User Manual

420
7 APPLICATION INSTRUCTION
7.7 Real Number Instruction
Dividing single-precision real numbers
E/(P)
These instructions divide the single-precision real number in the device specified by (s1) by the single-precision real number
in the device specified by (s2), and store the result in the device specified by (d).
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions divide the single-precision real number in the device specified by (s1) by the single-precision real
number in the device specified by (s2), and store the result in the device specified by (d).
• Values in the devices specified (stored) by (s1), (s2), and (d) should be 0 or 2
-126
<|specified value (stored value)|2
128
.
• When an input value is set from the engineering tool, a rounding error may occur.
• The table below shows the related devices.
Ladder diagram Structured text
Not supported
Operand Description Range Data type Data type (label)
(s1) Dividend data or head device number where the data which
is divided by another is stored.
0, 2
-126
|(s1)|<2
128
Single-precision real number Single-precision real number
(s2) Divisor data or head device number where the data that
divides another is stored.
0, 2
-126
|(s2)|<2
128
Single-precision real number Single-precision real number
(d) Head device number for storing the operation result  Single-precision real number Single-precision real number
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)   
(s2)   
(d)          
Device Name Description
Condition Operation
SM700 Carry The absolute value of the operation result  2
128
The value of (d) is the maximum value (2
128
) of 32-bit real
numbers and the carry flag SM700 turns on.
SM8020 Zero The operation result is true "0".
(The mantissa part is "0").
The zero flag SM8020 turns on.
SM8021 Borrow The absolute value of the operation result < 2
-126
The value of (d) is the minimum value (2
-126
) of 32-bit real
numbers and the borrow flag SM8021 turns on.
SM8022 Carry The absolute value of the operation result
 2
128
The value of (d) is the maximum value (2
128
) of 32-bit real
numbers and the carry flag SM8022 turns on.
(s1) (s2) (d)

(s1)(s1)+1 (s2)(s2)+1 (d)(d)+1
Single-precision real number Single-precision real number Single-precision real number
