266
6 BASIC INSTRUCTIONS
6.5 Data Conversion Instructions
Converting 16-bit binary data to Gray code
GRY(P)(_U)
These instructions convert the 16-bit binary data in the device specified by (s) to 16-bit binary gray code data, and store the
converted data in the device specified by (d).
■Descriptions, ranges, and data types
■Applicable devices
• These instructions convert the 16-bit binary data in the device specified by (s) to 16-bit binary gray code data, and store the
converted data in the device specified by (d).
The data conversion speed depends on the scan time of the CPU module.
There is no operation error.
Ladder diagram Structured text
ENO:=GRY(EN,s,d);
ENO:=GRYP(EN,s,d);
ENO:=GRY_U(EN,s,d);
ENO:=GRYP_U(EN,s,d);
Operand Description Range Data type Data type (label)
(s) GRY(P) Binary data or the head device where the binary
data is stored
0 to 32767 16-bit signed binary ANY16_S
GRY(P)_U 0 to 65535 16-bit unsigned binary ANY16_U
(d) GRY(P) Head device for storing the gray code data after
conversion
16-bit signed binary ANY16_S
GRY(P)_U 16-bit unsigned binary ANY16_U
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)
(d)
(s) BIN
(d)
00000
00000 00 0 00 0
00 0
1111
11 11
111
1
1
1234
1234
b15
b15
b0
b0
···
Gray code
16 bits
