Mitsubishi MELSEC iQ-F FX5 series User Manual

7 APPLICATION INSTRUCTION
7.7 Real Number Instruction
441
7
Calculating the cosine of single-precision real number
COS(P)/DCOS(P)
These instructions calculate the cosine of the angle specified by (s), and store the operation result in the device specified by
(d).
The COS(P) instructions can also be used as DCOS(P).
*1 The COS instruction is not supported by the ST language. Use COS of the standard function.
Page 772 COS(_E)
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions calculate the cosine of the angle specified by (s), and store the operation result in the device specified
by (d).
• Set the angle data in radians (angle180).
• The table below shows the related devices.
Operation error
Ladder diagram Structured text
*1
ENO:=COSP(EN,s,d);
Operand Description Range Data type Data type (label)
(s) Angle data or head device number where the angle data is
stored
 Single-precision real number Single-precision real number
(d) Head device number for storing the operation result  Single-precision real number Single-precision real number
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)   
(d)          
Device Name Description
Condition Operation
SM700 Carry The absolute value of the operation result  2
128
The value of (d) is the maximum value (2
128
) of 32-bit real
numbers and the carry flag SM700 turns on.
SM8020 Zero The operation result is true "0".
(The mantissa part is "0").
The zero flag SM8020 turns on.
SM8021 Borrow The absolute value of the operation result < 2
-126
The value of (d) is the minimum value (2
-126
) of 32-bit real
numbers and the borrow flag SM8021 turns on.
SM8022 Carry The absolute value of the operation result
 2
128
The value of (d) is the maximum value (2
128
) of 32-bit real
numbers and the carry flag SM8022 turns on.
Error code
(SD0/SD8067)
Description
3402 The specified device value is -0, denormalized number, NaN (not a number), or .
(s) (d)
(s)+1 (s) (d)+1 (d)
COS ( )
Single-precision real number Single-precision real number
