6 BASIC INSTRUCTIONS

6.6 Data Transfer Instructions

Transferring 16-bit data

MOV(P)

These instructions transfer the 16-bit binary data in the device specified by (s) to the device specified by (d).

Setting data

■Descriptions, ranges, and data types

■Applicable devices

Processing details

• These instructions transfer the 16-bit binary data in the device specified by (s) to the device specified by (d).

Operation error

There is no operation error.

Ladder diagram Structured text

ENO:=MOV(EN,s,d);

ENO:=MOVP(EN,s,d);

Operand Description Range Data type Data type (label)

(s) Transfer source data or device number for storing data -32768 to +32767 16-bit signed binary ANY16

(d) Transfer destination device number  16-bit signed binary ANY16

Operand Bit Word Double word Indirect

specification

Constant Others

X, Y, M, L,

SM, F, B, SB

U\G T, ST,

C, LC

T, ST, C, D,

W, SD, SW, R

U\G Z LC LZ K, H E $

(s)       

(d)       

(s) (d)

(d)

(s)

···

b15

b15 b0

101 01100011 10010

Transferred

Mitsubishi MELSEC iQ-F FX5 series User Manual
