7 APPLICATION INSTRUCTION
7.10 Data control instruction
7.10 Data control instruction
Upper and lower limit control of 16-bit binary data
LIMIT(P)(_U)
These instructions control the output value to be stored in the device specified by (d) by checking the input value (16-bit binary
data) in the device specified by (s3) with the upper and lower limit values specified by (s1) and (s2).
*1 The LIMIT_U instruction is not supported by the ST language. Use LIMIT of the standard function.
Page 806 LIMIT(_E)
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Ladder diagram Structured text
*1
ENO:=LIMIT(EN,s1,s2,s3,d);
ENO:=LIMITP(EN,s1,s2,s3,d);
ENO:=LIMITP_U(EN,s1,s2,s3,d);
Operand Description Range Data type Data type (label)
(s1) LIMIT(P) Lower limit value (minimum output value) -32768 to 32767 16-bit signed binary ANY16
LIMIT(P)_U 0 to 65535 16-bit unsigned binary
(s2) LIMIT(P) Upper limit value (maximum output value) -32768 to 32767 16-bit signed binary ANY16
LIMIT(P)_U 0 to 65535 16-bit unsigned binary
(s3) LIMIT(P) Input value controlled by the upper and lower limit values -32768 to 32767 16-bit signed binary ANY16
LIMIT(P)_U 0 to 65535 16-bit unsigned binary
(d) LIMIT(P) Head device number storing the output value controlled by
the upper and lower limit values
 16-bit signed binary ANY16
LIMIT(P)_U 16-bit unsigned binary
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)       
(s2)       
(s3)       
(d)       
(s1) (s2) (s3) (d)
