Mitsubishi MELSEC iQ-F FX5 series User Manual

7 APPLICATION INSTRUCTION
7.7 Real Number Instruction
447
7
Calculating the arc cosine of single-precision real number
ACOS(P)/DACOS(P)
These instructions calculate the angle from the cosine of the angle specified by (s), and store the operation result in the word
device specified by (d).
The ACOS(P) instructions can also be used as DACOS(P).
*1 The ACOS instruction is not supported by the ST language. Use ACOS of the standard function.
Page 775 ACOS(_E)
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Processing details
• These instructions calculate the angle from the cosine of the angle specified by (s), and store the operation result in the
device specified by (d).
• The cosine value specified by (s) can be set ranging from -1.0 to 1.0
• The angle (operation result) stored in (d) is expressed in radians (0 to ).
• The table below shows the related devices.
Ladder diagram Structured text
*1
ENO:=ACOSP(EN,s,d)
Operand Description Range Data type Data type (label)
(s) A cosine value used in COS
-1
(arc cosine) operation or
head device number storing the cosine value
-1.0 to +1.0 Single-precision real number Single-precision real number
(d) Head device number for storing the operation result 0 to  Single-precision real number Single-precision real number
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s)   
(d)          
Device Name Description
Condition Operation
SM700 Carry The absolute value of the operation result  2
128
The value of (d) is the maximum value (2
128
) of 32-bit real numbers
and the carry flag SM700 turns on.
SM8020 Zero The operation result is true "0".
(The mantissa part is "0").
The zero flag SM8020 turns on.
SM8021 Borrow The absolute value of the operation result < 2
-126
The value of (d) is the minimum value (2
-126
) of 32-bit real numbers
and the borrow flag SM8021 turns on.
SM8022 Carry The absolute value of the operation result
 2
128
The value of (d) is the maximum value (2
128
) of 32-bit real numbers
and the carry flag SM8022 turns on.
(s) (d)
(s)+1 (s) (d)+1 (d)
COS
-1
( )
Single-precision real number Single-precision real number
