5 SEQUENCE INSTRUCTIONS
5.7 Stop Instruction
143
5
5.7 Stop Instruction
Stopping the sequence program
STOP
This instruction resets outputs (Y) and stops operation of the CPU module when the execution command turns ON. (This
operation is the same as setting the switch to STOP.)
• This instruction resets outputs (Y) and stops operation of the CPU module when the execution command turns ON. (This
operation is the same as setting the switch to STOP.)
• To restart operation of the CPU module after this instruction is executed, return the switch from RUNSTOP and set it to
RUN again.
Ladder diagram Structured text
ENO:=STOP(EN);
Error code
(SD0/SD8067)
Remarks
3340 The STOP instruction is executed before the NEXT instruction is executed after the FOR instruction is executed.
3381 The STOP instruction is executed before the RET instruction is executed after the CALL(P) or XCALL(P) instruction is executed.
3582 The STOP instruction is executed before the IRET instruction is executed in the interruption program.
