17 ARITHMETIC OPERATION FUNCTIONS
17.7 Move Operation
789
17
17.7 Move Operation
MOVE(_E)
These functions output the assignment of input values.
Setting data
■Descriptions, types, and data types
Processing details
■Operation processing
• These functions assign the value of variable specified to (s) to the variable specified to (d).
• BOOL, INT, DINT, WORD, DWORD, REAL, STRING, TIME, structure, or array type can be specified for (s) and (d). Specify
the same data type for (s) and (d).
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=MOVE(s);
[With EN/ENO]
d:=MOVE_E(EN,ENO,s);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s Input Input variable ANY
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable ANY
sd
EN ENO
ds
INT
12
INT
12
(s) (d)
DINT
2147483647
DINT
2147483647
(s) (d)
WORD
65535
WORD
65535
(s) (d)
DWORD
4294967295
DWORD
4294967295
(s) (d)
REAL
3.402823+38
REAL
3.402823+38
(s) (d)
