Mitsubishi MELSEC iQ-F FX5 series User Manual

830
23 TIME DATA FUNCTIONS
23.1 Addition
23 TIME DATA FUNCTIONS
23.1 Addition
ADD_TIME(_E)
These functions output the sum of input values (TIME data) ((s1) + (s2)).
Setting data
■Descriptions, types, and data types
Processing details
■Operation processing
• These functions add the TIME type data input to (s1) and (s2) ((s1) + (s2)), and output the operation result from (d) as TIME
type data.
Ex.
When a value input to (s1) and (s2) is T#1d2h33m44s55ms (1 day 2 hours 33 minutes 44 seconds 55 milliseconds) and
T#2ms (2 milliseconds)
• A value input to (s1) and (s2) is the TIME type data value.
• Even if underflow or overflow occurs in the operation result, it is not regarded as an operation error. The data is output from
(d) as follows: "ADD_TIME_E" outputs "TRUE" from the output variable ENO.
Ex.
Overflow
The most significant bit becomes 1, and a negative time is output.
Ex.
Underflow
The most significant bit becomes 0, and a positive time is output.
Ladder diagram Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=ADD_TIME(s1,s2);
[With EN/ENO]
d:=ADD_TIME_E(EN,ENO,s1,s2);
Argument Description Type Data type
EN Execution condition (TRUE: Execution, FALSE: Stop) Input variable BOOL
s1, s2 Input Input variable TIME
ENO Output status (TRUE: Normal, FALSE: Abnormal) Output variable BOOL
d Output Output variable TIME
s1 d
s2
EN ENO
ds1
s2
TIME
T#1d2h33m44s55ms
TIME
T#1d2h33m44s57ms
(d)
TIME
T#2ms
(s2)(s1)
(7FFFFFFFH)
T#24d20h31m23s647ms
(80000001H)
T#-24d20h31m23s647ms
(00000002H)
T#2ms
(80000000H)
T#-24d20h31m23s648ms
(7FFFFFFEH)
T#24d20h31m23s646ms
(FFFFFFFEH)
T#-2ms
